Types |
Fluorine free |
|
Thickness |
10μm |
|
Color |
White |
|
Air permeability@125Kpa |
17200ml/sec/cm2 |
|
High temperature resistance |
-40°C~260°C |
|
Loss of sound(@1kHz) |
≤0.5dB（D1.5mm） |
Protection applications for SMT components
Material: polyurethane
Color: White
Thickness: 10μm
Air permeability (ml/cm²/min@7kPa): >12000
Particle filtration rate (5μ) : >100%
High temperature resistance: 260℃ for 3min
Breathable membrane (fluoride-free) PFAS: PASS
